SAE 100 R1 A hydraulic hose has excellent performance in delivering oil because of its oil resistant synthetic rubber tube.

SAE 100 R1 A hydraulic hose, also called DIN EN 853 1ST hydraulic hose, is similar to SAE 100 R1 AT hydraulic hose in structure. It is also composed of three parts: tube, reinforcement and cover. Tube is made from black oil resistant synthetic rubber, making hose have excellent performance in delivering hydraulic oils. Reinforcement is made from one high tensile and high strength steel wire braid, which is specialized for rubber hose. And the reinforcement makes hose have solid structure and bear high working pressure. Cover is made from black oil, corrosion and abrasion resistant synthetic rubber, making hose resistant to weather, ozone, heat and aging. It needs outer rubber layer stripping in withholding joints for this kind of hydraulic hose.

The details of SAE 100 R1 A hydraulic hose:

• Structure: it is composed of three parts: tube, reinforcement and cover.
  • Tube: black oil resistant synthetic rubber.
  • Reinforcement: one high strength and high tensile steel wire braid.
  • Cover: black oil, corrosion and abrasion resistant synthetic rubber.
• Temperature range: -40 °C to +100 °C.
• Hose ID: 6.4 mm - 50.8 mm.
• Reinforcement OD: 11.1 mm - 60.2 mm.
• Hose OD: 15.9 mm - 66.7 mm.
